Surron’s First Full-Size Electric Dirt Bike
Surron™ is setting another benchmark in the electric off-road world with the 2023 Storm Bee F. With 22.5 kW of electric power in a full-size package, the Storm Bee is for savvy off-road riders ready to make the shift from gas-powered engines. Imagine no more oil changes, no spilled gas, no top-end rebuilds… and no noise. Just plug in, charge up, and ride. The lack of emissions and noise will keep the neighbors happy; the performance will keep you happy.
With 120 km (75 miles) of max range and 520 Nm of torque, the 2023 Storm Bee F performs as well as it looks. Whether you’re heading out to carve some single-trail or a weeknight of laps at the local MX track, the Storm Bee delivers a seat-of-the-pants riding experience like few other off-road bikes can. And it’ll turn heads everywhere you go.
The North American version of the 2023 Storm Bee F comes as an off-road-only model. Unique to the North American version, you’ll receive both a headlight and number plate to cater the bike to your taste and riding environment.
KEY FEATURES OF THE STORM BEE F
- Liquid-cooled, brushless electric motor
- 22.5 kW peak power, 520 Nm peak torque
- Max. range: 120 km (75 miles) on a full charge @ 50 km/h (31 mph)
- 3 riding modes, traction control, regenerative braking
- Turbo mode & reverse gear
- Adjustable off-road suspension, 21/18” wheels (front/rear)
- Quiet & emissions-free
- Switchable headlight & number plate included (North American version only)
DOWNLOAD OWNER’S MANUAL
TECHNICAL SPECIFICATIONS
POWERTRAIN
| Motor Type | Liquid-cooled, brushless electric (BLDC) motor |
| Rated Voltage | 104V (DC) |
| Rated Power/Peak Power | 10,000W/22,500W |
| Controller Type | FOC Sine Wave |
| Peak Torque | 520 Nm (383 ft-lbs) |
| Top Speed | 110 km/h (68 mph) |
| Max Range | 120 km @ 50 km/h (75 miles @ 31 mph), depending upon terrain) |
| Battery | 104V/55Ah Lithium Ion |
| Charger | 10A |
| Charging Time | 4 Hours (0-100%) |
| Drive | 530 O-ring Chain |
RIDER AIDS
| Riding Modes | Sport, Rain, Eco, Turbo |
| Rider Aids | ASR (Acceleration Slip Reduction, a.k.a. traction control), BERS (Brake Energy Regenerative System) |
| Reverse Gear | Button-activated |
CHASSIS
| Front Suspension | 47 mm inverted fork, 290 mm travel, adjustable compression & rebound |
| Rear | Fully adjustable monoshock, 290 mm wheel travel |
| Front Wheel | 21″ wire-spoked rim, 80/100-21 off-road tire |
| Rear Wheel | 18″ wire-spoked rim, 100/90-18 off-road tire |
| Curb Weight | 127 kg (280 lbs) |
| Max Load | 100 kg (220 lbs) |
| Vehicle Dimensions | 2,080 mm x 805 mm x 1,240 mm (81.9 x 31.7 x 48.8”) |
| Minimum Ground Clearance | 310 mm (12.2″) |
| Wheelbase | 1,430 mm (56.3″) |
| Seat Height | 940 mm (37″) |
ADDITIONAL FEATURES
| USB Connection | Single USB-2.1A Outlet |
| Instrumentation | LCD Digital Dash |
| Headlight | LED |
Specifications subject to change without notice. Battery ranges are estimated. Actual range may vary.
IMPRESSIVE FRAME DESIGN
TURBO & REVERSE BUTTONS
Two of the most unique features on the Surron Storm Bee are turbo and reverse. Pressing the turbo button gives you a short, extra boost of power at full throttle. Meanwhile, the functional reverse button will be a welcome feature for riders who find themselves in tricky situations on the trail. It’s this kind of innovation and outside-the-box thinking that sets Surron apart.
HIGH PERFORMANCE ELECTRIC POWERTRAIN
The heart of the Storm Bee’s powertrain is its 104V/55Ah battery pack, powerful enough to propel the Storm Bee to a top speed of 75 mph and a max range of 70 miles. Recharge the Storm Bee via its included charger through a conventional wall outlet in 4 hours.
